• Fully automatic disc filling machine
  •   hot:1552


  • Fully-auto liquid filling machine components

           Fully-auto feeding bottle machine,
     Filling machine,
    conveyor belt,
    auto cap-loading machine,
    capping machine,
    control panel,
    air compressor



    QM-SY filling machine series
    1.      Application
    Filling cosmetic, perfume, shampoo, sterile water, liquor, soy sauce, oyster sauce, lubricant oil etc



    2.      Performance

    The machine is fully functional, reasonable design. Accurate, easy to clean, stable performance, is a new type filling equipment. Design of 1-4 filling head, easy to change the color of the manufacturers of materials and to clean the pump head, efficiency and make more.

    Automatic ointment filling machine with programmable control PLC interface technology, equipped with imported photoelectric tracking switch, paste filling for Yu Gaoshuang, oil, syrup, fruit juice, ketchup, shampoo and other industry production, filling nozzle automatic bottle filling, and the rapid rise, reducing the bubble. Product set in one of the motor, pneumatic, reasonable design, good stability, accurate quantity, glass table, automatic bottle, easy washing, filling equipment model is the best choice for the realization of automatic production


    3.      Feature

    a.        nice design, compact structure
    b.       high capacity
    c.        filling nozzle could go down and up
    d.       conveyor belt driven by step motor. no bottle moving when filling
    e.        easy to adjust, no bottle no filling
    f.        count function

    Feature
    1.      This machine adopts compressed air driven, so it is particularly suitable for use in a proof and damp environment, with a high degree of security
    2.      Due to the adoption of pneumatic control, and the use of mechanical positioning, so the filling precision is high, the accuracy can be controlled within 1%
    3.      The screw rod, the counter, the adjustment of filling volume is accurate, and can be directly reflected in digital form
    4.      In case of need to stop, just press the emergency stop switch, the piston automatically return to the initial position, filling stop
    5.      The equipment failure rate is extremely low


    Pls note: This machine can choose customized filling capacity, maximum filling 5L, suitable for soy sauce, vinegar, wine, oil, pesticide, shampoo, shower gel, hand washing liquid containing granular liquid, semi fluid materials

     Technical Parameter
    model QMGZ-200 QMGZ-500 QMGZ-1000 QMGZ-2500 QMGZ-5000
    Fill volume 5-120ml 25-250ml 50-500ml 100-1000ml 300-5000ml
    ideal fill volume 5-120ml 25-250ml 50-500ml 100-1000ml 300-5000ml
    Air supply 4-6kg/cm2 4-6kg/cm2 4-6kg/cm2 4-6kg/cm2 5-6kg/cm2
    Speed 0-25
    pcc/min    		 0-25 pcc/min 0-20
    pcc/min    		 0-15
    pcc/min    		 0-10
     pcc/min
    Precision 1% 1% 1% 1% 1%
    Weight 35kg 35kg 35kg 35kg 45kg










×
×
