  • QMFS up and down disperser

    Mainly used in chemical, material pretreatment, primary processing of materials, but also can complete a simple
    product. Speed, so that the material is well dispersed in different working speed, uniform. Very stable chemical
    equipment. Can be customized according to the actual production.

    Model Power
    KW    		 Max up
    MM    		 Speed
    RPM    		 capacity
    L    		 Impeller dia
    MM    		 Power supply
    V    		 Weight
    KG
    QM-FS-50 1.5 800 0-3000 10-50 150 380/220 80
    QM-FS-100 2.2 800 0-3000 50-100 200 380/220 100
    QM-FS-200 3.0 800 0-3000 50-100 250 380/220 120
    QM-FS-300 4.0 1000 0-3000 100-200 250 380/220 130
    QM-FS-400 5.5 1000 0-3000 200-500 300 380/220 150
    QM-FS-500 7.5 1200 0-3000 500-1000 350 380/220 180

















×
×
