    Description

         GMJ Liquid mixer Is the essential equipment in the chemical industry, it is suitable for mixing different materials mixing, such as the production of mixed liquid soap, shampoo, etc. the mucus dissolving, mixing, stirring, heating, cooling, stirring, homogenizing temperature control and other functions, is the ideal equipment in daily chemical industry.

    Function

    1、The mixing system adopts advanced frequency control, suitable for different requirements of the production process.

    2、According to the technical requirements for heating or cooling the material, the heating mode can be selected according to customer requirements steam or electric heating.

    3、There are a variety of impeller form, suitable for different types of products.

    4、The material is  SUS304 or SUS316L stainless steel, tank and pipe for the mirror polishing.

    5、vacuum pump is optional，for bubble free.

    6、bottom homogenizer or pipeline homogenizer is up to you.

    7、Stainless steel cabinet full monitoring equipment can be run, and can display the data of temperature, stirring speed etc..


    Technical Parameter

    Model GXJ-500 GXJ-1000 GXJ-2000 GXJ-3000
    capacity 500 L 1000 L 2000L 3000 L
    temp ≤100 ℃ ≤100 ℃ ≤100 ℃ ≤100 ℃
    Jacket pressure Normal pressure Normal pressure Normal pressure Normal pressure
    Stir speed 0-60r/min 0-60r/min 0-60r/min 0-60r/min
    Homogenizer speed 2880r/min 2880r/min 2880r/min 2880r/min
    Power supply 50-60Hz
     380V±10%-15%    		 50-60Hz
     380V±10%-15%    		 50-60Hz
     380V±10%-15%    		 50-60Hz
     380V±10%-15%





×
×
